ROTATION UNIT

COMPACTA ROTA

Pre-cleaning

Rotation unit with PLC control for the electroplating of metals.

Rotation unit for pre-cleaning

Rotation unit for electrochemical surface treatment of individual parts and samples, right up to series production. The system is controlled by a PLC control system with digital display.

Rotation unit
PLC
Round anode
Heating

COMPACTA ROTA

ROTA

Areas of application

ELEKTROLYTISCHES ENTFETTEN

Metals

& further precious metals

ROTATION UNIT

COMPACTA ROTA

Uniform deposition rates can be achieved by optimising the anode-cathode distance in combination with a time-controlled rotation unit. The ROTA rotation unit is equipped with a high-quality rectifier with Ah / preselection counter (Ah, Amin; Asec), timer, ramp and circulation pump for a uniform flow.

Model
ROTA 60
ROTA 2040
Power supply
230V AC 50 Hz
Power consumption
ca. 3,3 kW
max. 1500 mm
Working height
950 mm
Width
900 mm
Depth
710 mm
Weight
ca. 100 kg
Max. rotational speed
7,2 U/min
2,5 U/min

Rectifier - professional

10V/100A
LCD display, preset counter, timer

PLC control

Display: 6 lines, 3 background colours, 2 Ethernet ports

Magnetic drive pump

Power: 20 watts; Voltage: 200 - 240 V H 4m - V 6.0 l/min

Filter unit T1

Inlet/outlet: d=16 mm

Round anode

Platinised titanium anode
Stainless steel anodes

Rotation unit

Motor: 12 VDC, n=5 U/min

Holder for racks

5 rows of 30 stainless steel hooks per row
(or customised version)

Radiator

Power: 2000 W , 230 V

Edge extraction

with D75 mm suction nozzle

Anode frame

Stainless steel
Edit template

ROTATION UNIT

Uniform separation.

Rotation control via PLC
  • Rotation individually adjustable or controllable via PLC
  • Control of the direction of rotation, rotation speed and time
  • Direction of rotation right/left programmable in time
Temperature control
  • Radiators can be operated manually via an on/off switch
  • Continuous temperature control via controller
Filter unit
  • Solid filter unit operated via on/off switch
DC power source
  • Current and voltage are continuously adjustable
  • With Ah/pre-selection counter (Ah, Amin; Asec) and adjustable rectifier cut-off for optimum separation results
  • Rectifier control via start/stop switch
