circuit board plotter

CCD

With manual or automatic tool change

DRILLING & MILLING

CCD

The CCD milling and drilling plotters are computer-controlled drilling and milling machines that are available in various table sizes. They enable direct data processing of Excellon/Sieb & Meyer drilling data or HP/GL data. The systems are suitable for the production of PCBs (drilling, milling, insulation milling) as well as for milling and engraving plastics, aluminium and other metals. The systems can be equipped with a camera for calibration and inspection tasks.



In addition to the mechanics, the complete package includes the RoutePro and IsoCam software packages for controlling and preparing the layout design data and the drills and milling cutters used. A high-performance high-speed spindle achieves up to 60,000 rpm. Thanks to their robust design, various system sizes and equipment options, the systems are ideally suited for PCB production, front panel production or component manufacturing.

Up to

60,000 rpm

for precise drilling

Model
CCD M
CCD MW
CCD S
CCD SW
CCD XL
CCD CL W
Dimensions (mm)
[WxHxD]
700 x 550 x 300 mm
700 x 550 x 300 mm
700 x 800 x 300 mm
700 x 800 x 300 mm
700 x 850 x 300 mm
700 x 850 x 300 mm
work surface
(LxW) [mm]
270 x 325 x 38 mm
270 x 325 x 38 mm
325 x 495 x 38 mm
325 x 495 x 38 mm
500 x 600 x 38 mm
500 x 600 x 38 mm
Electrical connection
110240 V,
5060 Hz,
Vacuum cleaner
(1500 W)
Tool change
manually
automatically
manually
automatically
manually
automatic
Tool change
-
16
-
16
-
25
Weight
42 kg
13 kg
25 kg
17 kg
18 kg
23 kg
Scope of delivery

  • Mechanical unit
  • Control unit
  • High-frequency spindle
  • Mechanical milling depth limiter and drill hold-down device
  • RoutePro3000 (Windows XP - Windows 864bit) for drilling and milling
  • Powerful vacuum cleaner
  • Manual
  • USB Adapter
  • Key set
  • Automatic tool changer: Air hose

    • Accessories

  • Compressor
  • Measuring microscope
  • Drill/milling cutter
  • Drilling pads
  • Reference pins
  • Cooling device
  • Base material

    • DRILLING & MILLING

    PROPERTIES

    CCD circuit board plotter

    Spindle
    • KaVo high-precision spindle, 150 W, 63,000 rpm, with durable, heavy-duty bearings, including 3.2 mm (1/8") collet.
    • Software-controlled spindle speed
    • Electronic load control with software feedback.
    • Spindle quick stop (1s) and quick start
    • Drilling capacity: 5/s (= 18,000 holes per hour, hole pattern)
    Drive
    • High load 2x2 phase stepper motors
    • Maximum positioning speed per axis: 9000/mm/min (=150 mm/s)
    • Maximum working speed per axis: 9000/mm/min (=150 mm/s), individual setting per tool, independent of positioning speed
    • Step size selectable: 1 mil, ½ mil, ¼ mil (= 6.35 micrometers)
    • Drilling capacity: 5/s (= 18,000 holes per hour, hole pattern)
    • Accuracy: +/ 1 step
    • Positioning accuracy over the entire working path: 20 ppm (0.002%; 9.9 μm for working range 495 mm)
    Software
    • Integrated Windows control software for machine control, clear user interface, tool management and plausibility checks
    • Individually configurable working speed, spindle speed and depth infeed for each tool
    • Appropriate walking speed over the entire speed range
    • All machine parameters (speeds, acceleration ramps, X/Y/Z dimensions / scaling, drill breakage detection) configurable in software
    • Simple teach-in function for drilling data

    FURTHER SYSTEMS

    You may also be interested in

    Convert vertical conveyor system
